FEP flat tube for UV lamp protecting

FEP flat tube for UV lamp protecting

    • FEP flat  tube for UV lamp protecting
    • FEP flat  tube for UV lamp protecting
    • FEP flat  tube for UV lamp protecting
    • FEP flat  tube for UV lamp protecting
  • FEP flat  tube for UV lamp protecting

    Product Details:

    Place of Origin: China
    Brand Name: Prochema
    Certification: ISO

    Payment & Shipping Terms:

    Minimum Order Quantity: 50kgs
    Price: USD75 to USD80/kg
    Packaging Details: plastic bag and carton
    Delivery Time: 7-14 work days
    Payment Terms: T/T, Western Union
    Supply Ability: 10000kgs a month
    Contact Now
    Detailed Product Description
    UV Resistance: Can Be Used For UV Lamp Protecting Fireproof: VO Grade
    Anticorrosive: Can Be Used Many Fields Of Chemical,medical ,petrochemical Insulation: Perfect Electric Insulation Products
    Heat Resistance: Can Be Used Between-80 To 200C Degree Notoxice: Can Be Used In Human Body And Food /medical Fields
    Perfect Tolerance: 1-2mm

     FEP flat tube for UV lamp protecting

    Why advice you accept the flat FEP heat shrink tube for UV lamp?

     1.it won't effect your cover the lamp

      2.Saving your much shipping cost

      3. keep in stock easily

    FEP has very good charactor of heat resistance ,electric resistance,chemical resistance. It is widely used in Aviation spaceflight,instrument,Medical treatment Pharmacy,Electric instrument,Post &ccommunication,Petrochemical,Metallurgy &electric power,home electri products,illmination &illume.

    There are two methods to produce FEP film . Mould&blowing and Tape-casting .




    1:non-stick ,

    2:corrosion resistant
    3:high/low temperature resistance
    4:High diaphaneity



    • Agglutinant
    • electric iron board producing
    • F4 wax cloth belt, transmission belt combining adhibiting
    • F4 copper board inner adhibiting
    • Window
    • Electroanalysis
    • High temperature tape raw material
    • Capacitance raw material
    • Biology temperature protecting material
    • Non-metal compensator in thermo-eletric plant
    • Flameproof electric machinery
    • Surface protecting material

    Note: If you need any products of ours, please kindly contact with us directly by following contaction . Then we can reply you faster and easy . Thanks

    FEP flat  tube for UV lamp protecting


    Good adherence .

    Good adherence to mental.

    High and low temperature preservation

    -200~200°C high temperature intensity better than F4

    No-begriming ,and no-stagnant in tube

    Touching point θ=114°

    Security and insulation

    Under 60HZ—60MHZ high and low temperature , permittivity is 2.1.

    If firing, and will still insulate .

    Volume resistance more than1018Ωm

    Surfce resistance more than 2 X1013Ω

    Voltaic Arc more than 165 seconds insulation

    High diaphaneity

    Good penetrability in ultraviolet radiation,and lowest refraction coefficient

    High diaphaneity

    Lowest refractive index in plastic material


    Under ozone and sunshine for long time

    Easy to process for second time


     Dia 5mm to 200mm   post-shrink thickness 0.02 to 0.3mm




    FEP Main Properties

    Item Value
    Tensile Strength MPa28
    Elongation @ Break) %250
    Relative Density 2.14~2.17


    Thickness Width (flat width,double layers)
    0.0125 --0.3mm 50-300mm
    0.0125 to 0.15mm 50-1000mm
    0.5 to 3 300-1200mm (sheet)



    Package :

    Plastic bag &carton . Customized is acceptable
